GENTEQ Motor 1/3 HP MODEL HC 39GE 472 V832BS ZJ7 1110 RPM 400/460 V 1 AMP 1 PH

GENTEQ MOTOR

1/3 HP

MODEL HC 39GE 472 V832BS

ZJ7 WA6D

1110 RPM

 400/460 V 1 AMP 1 PH

Genteq HC39GE472 (V832BS) is an OEM 1/3 HP, 400/460V, single-phase condenser fan motor primarily manufactured for Carrier, Bryant, and Payne HVAC systems

• Motor SpecificationsHorsepower: 1/3 HP
• Speed: 1110 RPM
• Voltage: 400/460 V
• Amperage: 1.0 Amp
• Phase: 1 PH (Single Phase)
• Rotation: Clockwise (CW) when viewing the shaft end
• Frame/Type: Permanent Split Capacitor (PSC) or ECM equivalent depending on specific generation (requires a matching run capacitor if PSC).

The GENTEQ HC39GE472 V832BS is a reliable and efficient 1/3 horsepower motor, designed primarily for use in Carrier, Bryant, and Payne HVAC systems. Operating at 1110 RPM, this single-phase motor is suited for applications requiring a voltage range of 400 to 460 volts. It features a low current draw of 1 amp, making it an energy-efficient choice for responsible power consumption. Designed as an OEM condenser fan motor, it incorporates a permanent split capacitor (PSC) or ECM equivalent, optimizing performance for smooth and stable operation. The motor's rotation is clockwise when viewed from the shaft end, making it compatible with intended applications. For PSC units, a compatible run capacitor is necessary to ensure full operational capacity. This motor is made in the United States and supports a frequency rating of 60 Hz, ensuring compatibility with standard North American electrical systems. The GENTEQ HC39GE472 is a dependable component for maintaining optimal performance in HVAC systems, with a focus on longevity and efficiency. Its straightforward design allows for easy installation and reliable performance in various environments.
