APPLETON EXPLOSION PROOF BREAKER V58 30 AMP 600 V 3 POLE 3 PH EHD3030L

APPLETON EXPLOSION PROOF BREAKER

V58

30 AMP 600 V 3 POLE 3 PH

EHD3030L

The EHD3030L is a specific 30 Amp, 3 Pole, 3 Phase molded case circuit breaker manufactured by Eaton Cutler-Hammer (Series C, F-Frame lineup), which features standard line and load terminal lugs for standalone panel/enclosure mounting.

When combined with an Appleton explosion-proof enclosure, this breaker serves as the core internal mechanism for hazardous-location overcurrent and short-circuit protection. While the EHD breaker frame itself is technically rated for a maximum of 480V AC (with a 14 kAIC interrupting capacity at 480V), the surrounding Appleton heavy-duty explosion-proof enclosure assemblies or receptacle combinations (such as the AE or EBR series) are physically rated to isolate voltages up to 600V AC. [

Technical Specifications Internal Components

• Eaton Cutler-Hammer EHD3030L (F-Frame Series C)
• Current Rating: 30 Amps
• Configuration: 3 Pole, 3 Phase
• Breaker Voltage Limit: 480V AC / 250V DC
• Enclosure Assembly Insulation Max: 600V AC
• Trip Type: Non-interchangeable Fixed Thermal, Fixed Magnetic (LI - Long-Time & Instantaneous protection)
• Enclosure Environment (Appleton standard): Typically Class I, Div 1 & 2, Groups B, C, D; Class II, Div 1 & 2, Groups E, F, G; NEMA 7/9 explosion-proof cast aluminum.

This exact combination is commonly deployed in oil refineries, chemical plants, marine applications, and grain elevators where containment of an electrical arc is strictly mandatory.
